Soundstream TXP1.12000D 12000W Max (4300W RMS) Monoblock Class D 1-ohm Amplifier

Features:

• Soundstream Tarantula Series Class D 1 ohms Stable Monoblock Amplifier
• RMS Power Rating:
• 4 ohms: 1,300 watts x 1 channel
• 2 ohms: 2,300 watts x 1 channel
• 1 ohm: 4,300 watts x 1 channel
• Total RMS power output: 4,300 watts
• Silicone Steel Alloy Core Power Supply Transformers & Flux Capacitors
• Military Grade SMT PCB Maintains Dynamic Performance
• LED Accent Lighting Illuminates Circuit Board
• Wired remote bass level control included
• Soft start turn-on
• Direct Short, Thermal, & Overload Circuits Protect Amplifier
• Input sensitivity:
• Low level: 200 - 6 volts
• Frequency Response: 20 - 20,000 Hz
• Total Harmonic Distortion (THD): 0.3%
• Signal to Noise Ratio: 105 dB
• Variable low-pass filter: 80 - 20,000 Hz
• Variable Bass Boost: 0 - 12 dB
• 8 AWG gauge power and ground wiring are recommended for installation.
• Dimensions: 8.25" W x 7.25" L x 2.75" H

Specifications:

Power Specifications - Subwoofer Channel:

• RMS Power @ 4 ohms: 1,300 watts x 1 channel
• RMS Power @ 2 ohms: 2,300 watts x 1 channel
• RMS Power @ 1 ohm: 4,300 watts x 1 channel

Amplifier Specifications:

• Amplifier Series: Soundstream Tarantula Series
• Marine Certified: No
• Amplifier Class: D
• Number of Channels: 1 - Mono
• Total Peak Power Output: 12,000 watts
• Total RMS Power Output: 4,300 watts
• Maximum Input Gauge Size: 8 AWG
• Minimum Impedance Unbridged: 1 ohm
• Minimum Impedance Bridged: 4 ohms
• Frequency Response: 20 - 20,000 Hz
• THD at Rated RMS Power: 0.3%
• Speaker Level Inputs: Yes
• Preamp Outputs: 1 pair
• Built-in Crossover: Low-Pass (LP), High-Pass (HP)
• High-Pass Crossover Frequency: 15 - 80 Hz
• Low-Pass Crossover Frequency: 80 - 20,000 Hz
• Signal-to-Noise Ratio: 105 dB
• Bass Boost: 0 - 12 dB
• Remote bass/level controller: Yes
• Fan Cooled: No
• Strappable: No
• Amp Bluetooth Connectivity: No
• Low-Level Input Sensitivity: 200 - 6 volts
• High-Level Input Sensitivity: 200 - 6 volts
