Rockford Fosgate R500X1D
Rockford Fosgate R500X1D
Rockford Fosgate R500X1D
Rockford Fosgate R500X1D
Rockford Fosgate

Rockford Fosgate R500X1D

$145.99 0 items left

Sold out

BRAND: Rockford Fosgate SKU: R500X1D PRODUCT ID: 1870709162026 SHIPPING WEIGHT: 6.0 lb

2-6 DAYS DELIVERY

100% ORIGINAL AND QUALITY

1 YEAR MANUFACTURER WARRANTY

  • Description
  • Reviews

Features:

  • Prime Series Class D Monoblock Car Amplifier
  • RMS Power Rating:
    • 4 ohms: 300 watts x 1 chan.
    • 2 ohms: 500 watts x 1 chan.
  • CEA-2006 compliant amplifier
  • Efficient Class-D circuit topology
  • 12dB/octave Butterworth crossover
  • RCA pass-thru outputs
  • On-board Punch EQ with +18dB boost @ 45Hz.
  • High level inputs
  • Remote PLC (Punch Level Control)
  • 0°/180° Phase Switch
  • Real time output and power supply thermal sensing
  • Cast aluminum heatsink
  • 4 Gauge power/ground connectors
  • MOSFET power supply
  • Over current protection
  • Short circuit protection
  • Muted turn on
  • Frequency Response: 20 - 250 Hz +/- 1 dB
  • Efficiency: 89% @ 4-ohm
  • Total Harmonic Distortion: <1.0%
  • Signal to Noise Ratio: >100 dB
  • Damping Factor: >200 dB
  • Input Sensitivity: 150 mV - 4V
  • Recommended Fuse: 50A x 1 (not included)
  • 8-gauge speaker wire terminals

Specifications:

Power Specifications - Subwoofer Channel:

  • RMS Power @ 4 ohms: 300 watts x 1 channels
  • RMS Power @ 2 ohms: 500 watts x 1 channels

Amplifier Specifications:

  • Amplifier Series: Prime (Rockford Fosgate)
  • Amplifier Class: D
  • Number of Channels: 1 - Mono
  • Total Peak Power Output: 1000 watts
  • Total RMS Power Output: 500 watts
  • Maximum Input Gauge Size: 4 AWG
  • Minimum Impedance Unbridged: 2 ohms
  • Minimum Impedance Bridged: Not Bridgeable
  • THD at Rated RMS Power: <1.0%
  • Speaker Level Inputs: Yes
  • Preamp Outputs: 1 pair
  • Built-in Crossover: Low-Pass (LP)
  • Low-Pass Crossover Frequency: 50 - 250 Hz
  • Signal-to-Noise Ratio: >100 dB
  • Bass Boost: 0 - 18 dB
  • Bass/Gain Remote: Yes
  • Fuse Rating: 50A X 1 In-Line Fuse Recommended
  • Strappable: No
  • CEA-2006 Compliant: Yes
