Diamond Audio MSMP692LK 14+ Harley Davidson Cut in Lid Kit with MP692 (2Ω)
Diamond Audio MSMP692LK 14+ Harley Davidson Cut in Lid Kit with MP692 (2Ω)
Diamond Audio MSMP692LK 14+ Harley Davidson Cut in Lid Kit with MP692 (2Ω)
Diamond Audio MSMP692LK 14+ Harley Davidson Cut in Lid Kit with MP692 (2Ω)
Diamond Audio MSMP692LK 14+ Harley Davidson Cut in Lid Kit with MP692 (2Ω)
Diamond Audio MSMP692LK 14+ Harley Davidson Cut in Lid Kit with MP692 (2Ω)
Diamond Audio MSMP692LK 14+ Harley Davidson Cut in Lid Kit with MP692 (2Ω)
Diamond Audio MSMP692LK 14+ Harley Davidson Cut in Lid Kit with MP692 (2Ω)
Diamond Audio MSMP692LK 14+ Harley Davidson Cut in Lid Kit with MP692 (2Ω)
Diamond Audio MSMP692LK 14+ Harley Davidson Cut in Lid Kit with MP692 (2Ω)
Diamond Audio

Diamond Audio MSMP692LK 14+ Harley Davidson Cut in Lid Kit with MP692 (2Ω)

$999.99 3 items left
BRAND: Diamond Audio SKU: MSMP692LK PRODUCT ID: 7477297971381 SHIPPING WEIGHT: 12.0 lb

2-6 DAYS DELIVERY

100% ORIGINAL AND QUALITY

1 YEAR MANUFACTURER WARRANTY

  • Description
  • Reviews

Features:

  • Harley Davidson ® 14+ Cit in Lid Kit
  • Includes .5” 6” x 9” Spacer Ring
  • Includes MP692 Motor Sports 6” x 9” (2Ω) Marine Grade Speaker
  • Includes Plug-n-Play Wire Harness W/ DLED Wiring

Specifications:

  • Speaker Size: 6" X 9"
  • Description: 2014+ Harley Davidson Cut in Lid Kit with MP692 (2Ω) Speaker
  • Nominal Impedance (ohms): 2Ω
  • RMS Power Rating: 150W
  • Max Power Rating: 300W
  • Frequency Response: 80Hz -18Khz
  • Voice Coil Diameter (inch/mm): 1.5” Woofer/1.0” Tweeter
  • Power Handling (RMS/Peak): 150W/300W
  • Types: 2-way
  • Re (Ω)[series]: 1.8
  • Qms: 6.98
  • Qes: 0.68
  • Qts: 0.33
  • Fs-Free Air Resonance (Hz): 81.2
  • Vas (Liter): 18
  • Cms (mm/N): 0.15
  • Mms (g): 15.4
  • Sd (cm²): 227
  • BL (T*M): 6.4
  • Xmax - Inch(mm): 2
  • Total Diameter: 9.33"X6.57" (237mmX167mm)
  • Mounting Diameter (inch/mm): 8.86”x5.98” (225mmx152mm)
  • Mounting Depth: 3.99" (100mm)
  • Magnet Diameter (E): 3.94" (100mm)
  • Screw Hole Diameter: 4.26" (108.3mm)
  • Dimension - Length x Width x Height - Inches(mm): 6.574” x 9.37” (167mm/238mm)
