Diamond Audio MSMS694LK (2014-2023 Harley Davidson® Cut In Lid Kit with MS69CX (4Ω) Speaker) + MICRO2V2 (MICROV2 Series 2-Channel Full Range Class D Amplifier)

Features:

MSMS694LK Features:

• Seamless Integration: Designed specifically for Harley Davidson® models from 2014 +, the MSMS694LK kit guarantees a perfect fit and a factory-finish appearance, blending effortlessly with your bike's aesthetic.
• Superior Sound Quality: At the heart of this kit are the MS69CX Motorsports 6”x9” Marine Grade Speakers. With their robust 4Ω impedance, these speakers deliver rich, immersive audio, transforming your motorcycle into a mobile concert hall.
• Durability: Crafted to withstand the elements, the marine-grade speakers are designed for optimal performance in all weather conditions, ensuring your audio system remains as rugged as your bike.
• Complete Installation Kit: The package includes everything you need for a hassle-free installation. The included rubber gasket ensures a secure and vibration-free fit, while the plug-n-play wire harness with LED wiring simplifies the process, allowing you to get back on the road with minimal downtime.
• Enhanced Ride Experience: Whether you're cruising down the highway or parked at a rally, the MSMS694LK kit will provide the perfect soundtrack to your adventures, enhancing every moment with pristine audio quality.

MICRO2V2 Features:

• MicroV2 Series Class D 2 ohm Stable 2-Channel Amplifier
• RMS Power Rating:
• 4 ohm: 150 watts x 2 channel
• 2 ohm: 250 watts x 2 channel
• Bridged: 500 watts x 1 channel @ 4 ohm
• Total RMS power output: 500 watts
• LED Power/Protect Light
• Wired bass level remote control included
• Selectable turn-on mode (Remote, DC Offset, Signal Sensing)
• Advanced rollback and thermal protection
• Full range Class D IR chipset
• DirectFET power MOSFET output stage
• SMD technology on 4-layer glass PC board
• ICAD circuit provides superior overload protection
• Variable 12dB crossovers
• Ultra-compact and versatile
• Bluetooth receiver enabled for Diamond Audio Datura/12 Bluetooth receivers only
• Input sensitivity: 0.2 - 10 volts
• Frequency Response: 10 - 33 KHz
• Total Harmonic Distortion (THD): 0.5%
• Signal to Noise Ratio: -85 dB
• Variable high-pass filter: 40 - 400 Hz
• Variable low-pass filter: 40 - 400 Hz
• Variable Bass Boost: 0 - 12 dB
• Fuse Rating: 25A
• 8 AWG gauge amplifier wiring kit is recommended for installation
• Dimensions: 7.89" L x 4.0" W x 1.46" H

Specifications:

MSMS694LK Specifications:

• Includes .5” 6” x 9” Spacer Ring
• Includes MS69CX Motor Sports 6” x 9” Marine Grade Speaker
• Includes Plug-n-Play Wire Harness
• 6 X 9 2-Way High Power Motor Sport Coax-Sub
• Manufactured to IPx65 Marine Grade Compliant Specifications
• 1" High Output Titanium Dome Tweeter
• UV-Treated Thermal Molded Waterproof Kevlar Cone with Rubber Surround
• 12dB Bessel Crossover Network
• Super High Energy Ferrite Motor System With Milled Aluminum Top Plate
• T-Yoke Back Plate Drilled For 35% More Cooling, Increased Power Handling
• High-Temperature Cast Aluminum Basket

MICRO2V2 Specifications:

• 2 Channel Full Range Digital Amplifier
• 250W x 2CH @ 2Ω
• 150W x 2CH @ 4Ω
• 500W x 1CH @4Ω Bridged RMS Power Output
• Input Sensitivity: 0.2-10 Volt
• Crossover Filter : 40-400Hz, 12dB Per Octave Slope
• Frequency Response: 10-33KHz
• Selectable REM / VOX / DC Turn On Modes
• Selectable X-Over: LPF / FLAT / HPF
• Dimensions: 7.89” x 4.1” x 1.46” / 200.5 x 103 x 37.2 mm
• Remote Bass Knob Included
• Disconnected RCA Input & Speaker Output Harness Kits Included
