Diamond Audio MICRO82U 2-Channel MICRO8U Series Full Range Class D Car Amplifier (Refurbished)

Features:

• 2-Channel Full Range Class D Amplifier
• Up to 500W Max Power Output
• 150W x 2 @ 4Ω / 250W x 2 @ 2Ω / 500W Bridged
• Conformal-coated for All-Weather Durability
• Compact Design for Easy Installation
• Selectable REM / VOX / DC Turn-on Modes
• Adjustable Crossover and Input Sensitivity
• Includes RCA Input & Speaker Output Harness Kits

Specifications

2-Channel MICRO8U Series Full Range Class-D Amplifier

Power Rating

• Max Power : 500 W x 1
• RMS Power (2 Ω) : 250 W x 2
• RMS Power (4 Ω) : 150 W x 2
• Bridged (mono 4 Ω) : 500 W x 1

Power Supply

• Power Supply : Full PWM
• Power Supply Threshold : 10.0VDC - 17.0VDC
• Idle Current : (0.7A)

Distortion

• THD 4 (1KHz @4Ω) : 0.5%
• S/N Ratio (A Weighted @1W) : -85dBA
• S/N Ratio (A Weighted @ FP) : -101.1dBA

Input Sensitivity

• Low Input Level : 200mV - 10V
• High Input Level : N/A

Input Impedance

• Low Input Level : 20 KΩ
• AUX Input Level : 20 KΩ

Output Stage

• Output Impedance : 0.0297 Ω
• Damping Factor (50Hz @ 4Ω) : >250
• Bandwidth (-3dB) : 10Hz-30KHz

Crossover (-12dB/Oct)

• Variable High-Pass : 40Hz - 400Hz
• Variable Low-Pass : 40Hz - 400Hz
• Variable Sub-Sonic : N/A

Fuse Ratings

• ATC : 25A

Dimensions

• L x W x H : 9.0" x 4.06" x 1.52" (228.6 x 103.12 x 38.61)mm

THREE MONTHS LIMITED WARRANTY
