Rockford Fosgate Punch PM300X1

Rockford Fosgate
SKU: PM300X1
Availability: Out of stock
$299.99




Features:

  • Full-Range Monoblock Punch Series Class AB Marine Amplifier
  • RMS Power Rating:
    • 4 ohms: 200 watts x 1 chan.
    • 2 ohms: 300 watts x 1 chan.
  • Dynamic Power:
    • 4 ohms 0° Res : 260 watts x 1 chan.
    • 2 ohms 0° Res : 444 watts x 1 chan.
  • Includes a Rockford Fosgate Performance Verification Certificate
    w/ Inspection Data & Actual Power Rating, (aka "Birth Sheet")
  • CEA-2006 compliant amplifier
  • CE Compliant
  • LED power (blue) and protect (red) indicators
  • Muted turn on
  • Stealth top mounted control panel
  • Cast aluminum heatsink
  • Short circuit protection
  • Over current protection
  • Marine grade two part epoxy coating on circuit boards
  • Marine grade stainless steel hardware
  • Preamp RCA outputs to daisy chain multiple amps
  • Dual speaker terminals simplify the hookup of multiple speakers
  • Balanced Differential Inputs, to eliminate noise picked up by signal cables
  • Protected against Dust, UV, & Corrosion
  • Dynamic Thermal Management evenly distributes excess heat across entire amplifier heatsink.
  • Features MEHSA3 (Maximum Efficiency Heat Sink Application - gen3)
  • High level input capable with Auto Turn-On circuit:
    • Input sensitivity: 150 mV - 12 V
    • Frequency Response: 20 - 20,000 Hz
    • Efficiency (average): 74% @ 4-Ohm
    • Total Harmonic Distortion (THD): <1.0%
    • Punch EQ Bass: 0 - +18dB boost @ 45Hz.
    • Punch EQ2 Treble: 0 - +12.5dB @ 12kHz
    • 12dB/octave Butterworth crossover (selectable)
    • Variable high-pass filter: 50 - 250 Hz, 12 dB/octave
    • Variable low-pass filter: 50 - 250 Hz, 12 dB/octave
    • Recommended Fuse Rating: 50A x 1 inline (not included)
    • Operating Voltage: 9 - 16 VDC
    • Max Current Draw: 45 A
    • Average Current Draw: 23 A
    • Power Wire Gauge: 4 AWG - 8 AWG
    • Speaker Wire Gauge: 8 AWG - 18 AWG
    • Dimensions: 7.76 Inch W x 9.86 Inch L x 2.38 Inch H

    Specifications:

    Power Specifications - Full Range Channels:

    • RMS Power @ 4 ohms: 200 watts x 1 channels
    • RMS Power @ 2 ohms: 300 watts x 1 channels

    Amplifier Specifications:

    • Marine Certified: Yes
    • Amplifier Class: AB
    • Number of Channels: 1 - Mono
    • Total RMS Power Output: 300 watts
    • Maximum Input Gauge Size: 4 AWG
    • Minimum Impedance Unbridged: 2 ohms
    • Minimum Impedance Bridged: Not Bridgeable
    • THD at Rated RMS Power: <1.0%
    • Speaker Level Inputs: Optional (Requires Accessory Adapter)
    • Preamp Outputs: 1 pair
    • Built-in Crossover: Low-Pass (LP), High-Pass (HP), Full (AP)
    • High-Pass Crossover Frequency: 50 - 250 Hz
    • Low-Pass Crossover Frequency: 50 - 250 Hz
    • Bass Boost: 0 - 18 dB
