Rockford Fosgate PM400X2

Rockford Fosgate
SKU: PM-400X2
Availability: Out of stock
$349.99




Features:

  • 2-Channel Punch Series Class-ab Marine Amplifier
  • RMS Power Rating:
    • 4 ohms: 125 watts x 2 chan.
    • 2 ohms: 200 watts x 2 chan.
    • Bridged, 4 ohms: 400 watts x 1 chan.
  • Dynamic Power:
    (PVC/PowerCube)
    • 4 ohms: 149 watts x 2 chan.
    • 2 ohms: 256 watts x 2 chan.
  • Includes a Rockford Fosgate Performance Verification Certificate
    with Inspection Data & Actual Power Rating, (aka "Birth Sheet")
  • CEA-2006 compliant amplifier
  • CE Compliant
  • LED power (blue) and protect (red) indicators
  • Features C.L.E.A.N. Set-up with 10-step set-up procedure
  • Muted turn on
  • Stealth top mounted control panel
  • Cast aluminum heatsink
  • Short circuit protection
  • Over current protection
  • Marine grade two part epoxy coating on circuit boards
  • Marine grade stainless steel hardware
  • Preamp RCA outputs to daisy chain multiple amps
  • Balanced Differential Inputs, to eliminate noise picked up by signal cables
  • Protected against Dust, UV, & Corrosion
  • Dynamic Thermal Management evenly distributes excess heat across entire amplifier heatsink.
  • Features MEHSA3 (Maximum Efficiency Heat Sink Application - gen3)
  • Input sensitivity: 150 mV - 12 V
  • Frequency Response: 20 - 20,000 Hz
  • Efficiency (average): 72% @ 4-Ohm
  • Total Harmonic Distortion (THD): <1.0%
  • Punch EQ Bass: 0 - +18dB boost @ 45Hz.
  • 12dB/octave Butterworth crossover (selectable)
  • Variable high-pass filter: 50 - 250 Hz, 12 dB/octave
  • Variable low-pass filter: 50 - 250 Hz, 12 dB/octave
  • Recommended Fuse Rating: 60A x 1 inline (not included)
  • Operating Voltage: 9 - 16 VDC
  • Max Current Draw: 55A
  • Average Current Draw: 28A
  • Power Wire Gauge: 4 AWG - 8 AWG
  • Speaker Wire Gauge: 8 AWG - 18 AWG
  • 4 gauge OFC power and ground wiring is recommended for installation.
  • Dimensions: 7.76 Inch W x 11.03 Inch L x 2.38 Inch H

Specifications:

Power Specifications - Full Range Channels:

  • RMS Power @ 4 ohms: 100 watts x 2 channels
  • RMS Power @ 2 ohms: 200 watts x 2 channels
  • Bridged RMS Power: 400 watts x 1 channels

Amplifier Specifications:

  • Amplifier Class: AB
  • Number of Channels: 2
  • Maximum Input Gauge Size: 4 AWG
  • Minimum Impedance Unbridged: 2 ohms
  • Minimum Impedance Bridged: 4 ohms
  • THD at Rated RMS Power: <1.0%
  • Speaker Level Inputs: Optional (Requires Accessory Adapter)
  • Preamp Outputs: 1 pair
  • Built-in Crossover: Low-Pass (LP), High-Pass (HP), Full (AP)
  • High-Pass Crossover Frequency: 50 - 250 Hz
  • Low-Pass Crossover Frequency: 50 - 250 Hz
Manufacturer :Rockford Fosgate
Model : PM400X2
Weight :10.0 lb
SKU : PM-400X2
Warranty :
